One-stop Plastic Injction Solution Supplier since 2002
State-of-the-art technologies are introduced and upgraded for the more efficient and stable manufacturing of the product. 210T Vertical High Efficiency Seal Pad Plastic Injection Moulding Machine Price In India HM0160-28 functions perfectly in the application scenario(s) of Dental Floss Pick Making Machine. Innovation ability is the key to the core competitiveness of products. In the future,210T Vertical High Efficiency Seal Pad Plastic Injection Moulding Machine Price In India HM0160-28 will always adhere to the road of quality development, increase the investment in technology and talent introduction, always improve the core competitiveness of the enterprise, to achieve the goal of sustainable development.
| Plastic Processed: | PP, PC | Condition: | New |
| Style: | VERTICAL | Injection Rate (g/s): | 166.2 |
| Machine Type: | Hydraulic | Injection Weight (g): | 515 |
| Screw diameter (mm): | 55 | Distance between Tie Bars: | 1100*480 |
| Weight (KG): | 18000 | Type: | Tube Head Injection |
| Place of Origin: | Guangdong, China | Model Number: | HM160-28 abc |
| Brand Name: | HOMMAR | Power (kW): | 35 |
| Warranty: | 2 years | Key Selling Points: | Competitive Price |
| Applicable Industries: | Manufacturing Plant, seal pad | Plastic Type: | Thermoplastic |
| Automatic: | Yes | After-sales Service Provided: | Field maintenance and repair service, Engineers available to service machinery overseas |
| Opening Stroke: | 200mm | Certification: | ISO 9001:2008 |
| Clamping Force (kN): | 2058 | Keyword: | seal pad |
| Screw Diameter: | 45-55mm | Injection weight: | 300-515g |
| Clamping force: | 210 Ton | Molds: | 1 set |
| Oil Tank Capacity: | 560L | Cooling water: | 1500-2000L/hr |
| Dimension of Machine: | 3.4*2.4*4.8M | Packing Dimension: | 3.6*2.6*4.7M |
210T Vertical High Efficiency Seal Pad Plastic Injection Moulding Machine Price In India HM0160-28
| Spec | ||||
| Model | HM-210T-HS | |||
| Injection unit | Screw Diameter | mm | 45 | 55 |
| Injection Pressure | Kgf/cm3 | 2268 | 1560 | |
| Injection Capacity | cm3 | 300 | 515 | |
| Injection Weight | gr | 300 | 515 | |
| oz | 10.5 | 18.1 | ||
| Injection Rate | cc/s | 96.9 | 166.2 | |
| Screw Speed | r.p.m | 10-220 | ||
| Screw Stroke | mm | 200 | ||
| Nozzle Stroke | mm | 270 | ||
| Nozzle Contact Force | tf | 7 | ||
| Clamping unit | Clamping System | Hydraulic | ||
| Clamping Force | tf | 210 | ||
| Clamping Stroke | mm | 350 | ||
| Max.Mould Space | mm | 550 | ||
| Min.Mould Height | mm | 300 | ||
| Space between columns | 1100*480 | |||
| Hydraulic Ejector Force | tf | 7 | ||
| Ejector Stroke | mm | 50 | ||
| Slidable Stroke | ° | 600 | ||
| Tableda | Overall Size of Slipform | mm | 1200*1060 | |
| Number of Molds | set | 1 | ||
| Drive Motor | kw | 22(30HP) | ||
| Electrical Parts | Heater | kw | 13 | |
| Oil Tank Capacity | L | 550 | ||
| Cooling Water | L/hr | 1500-2000 | ||
| Dimension of Machine | M | 3.4*2.4*4.8 | ||
| Packing | Weight of Machine | T | 18 | |
| Shipping size | M | 3.6*2.6*4.7 | ||
| Shipping weight | T | 18.4 | ||
| Key Parts List | |||
| Part Name | Brand | Original of Country | Features |
| Computer | Star Denshi | Japan | High Precise Control, High sensitive response, TFT Color display |
| Servo Motor | YASKAWA | Japan | Energy Saving |
| Electromagnetic valve/ solenoid valve | Yuken | Japan | High sensitive response |
| hydraulic valve | HSUTIEN | Taiwan | Longer span life |
| Material Cylinder | Tan Star | Taiwan | Antia brasive corrosion resistance Longer span life |
| Electronic parts | Schneider Fuji Fotek | France/Japan/Taiwan | Stable High sensitive |
| hydraulic Motor | White | USA | Low noise |
| Servo Pump | Eckerle | Germany | Low noise |
| Electrical Ruler | Gefran | Italy | High Precise Control |
| Tiebar | Genaral | Taiwan | High hardness |
| Seal | HALLITE | UK | Longer span life |
| Proportional rejection valve | Yuken | Japan | High Precise Control Longer span life |
| Oil Cylinder | Lianhuei | Taiwan | Antia brasive |
