People with different backgrounds purchase 55T Vertical C Frame Jute Espadrille Shoe Sole Making Injection Molding HM0125-10 no matter the budget because of the effectiveness of these product. The Injection Molding Machine product will supply to all over the world, such as Europe, America, Australia,Uganda , Oman ,Sri Lanka , Surabaya . In aspect of the product design, our design team always pays close attention to the customers' taste and industry trends. Thanks to this, our 55T Vertical C Frame Jute Espadrille Shoe Sole Making Injection Molding HM0125-10 can fully attract people's attention with its unique appearance. Moreover, it is excellent performance, making it worth the investment.

Plastic Processed:PP, PCCondition:New
Style:VERTICALInjection Rate (g/s):98 g/s
Machine Type:HydraulicInjection Weight (g):146 g
Screw diameter (mm):40 mmDistance between Tie Bars:*
Weight (KG):4500Type:Tube Head Injection
Place of Origin:Guangdong, ChinaModel Number:HM125-10 abc
Brand Name:HOMMARPower (kW):12.6 kW
Warranty:2 yearsKey Selling Points:Automatic
Applicable Industries:Manufacturing Plant, jute espadrille shoe solePlastic Type:Thermoplastic
Automatic:YesAfter-sales Service Provided:Field maintenance and repair service, Engineers available to service machinery overseas
Opening Stroke:130 mmCertification:ISO 9001:2008
Clamping Force (kN):539Keyword:jute espadrille shoe sole
Screw Diameter:32-40mmInjection Pressure:1807-1156kgf*m3
Molds:1setOil Tank Capacity:220L
Cooling water:600-800L/hrDimension of Machine:2.6*1.4*2.45M
Packing Dimension:2.8*1.8*2.7MWeight of Machine:4500

555T Vertical C Frame Jute Espadrille Shoe Sole Making Injection Molding HM0125-10

Product Description
Spec
ModelHM-35TR-CHM-55TR-C
Injection unitScrew Diametermm2632323640
Injection PressureKgf/cm320711367180714271156
Injection Capacitycm36496104132163
Injection Weightgr578794119146
oz233.34.15.1
Injection Ratecc/s4467638098
Screw Speedr.p.m0-1800-180
Screw Strokemm120130
Nozzle Strokemm150150
Nozzle Contact Forcetf3.53.5
Clamping UnitClamping SystemHydraulic
Clamping Forcetf3555
Clamping Strokemm200200
Max.Mould Spacemm375375
Min.Mould Heightmm175175
Overall size of platens(HxV)mm420*240480*280
Hydraulic Ejector Forcetf1.71.7
Ejector Strokemm4040
Ejector Nozzle Strokemm140+/-25140+/-25
Dist. Between Center
 and Ejector nozzle
mm7575
Number of MoldsSet22
Electrical PartsDrive Motorkw5.5(7.5HP)7.5(10HP)
Heaterkw4.15.1
Oil Tank CapacityL160220
Cooling WaterL/hr600-800600-800
PackingDimension of Machinemm2.5*1.4*2.42.6*1.4*2.45
Weight of Machinetf3.54.5
Shipping sizemm2.7*1.8*1.62.58*1.8*2.7
Shipping weighttf4.25.2

Key Parts List

Part Name BrandOriginal of CountryFeatures
ComputerStar DenshiJapanHigh Precise Control,
High sensitive response,
TFT Color display
Servo MotorYASKAWAJapanEnergy Saving
Electromagnetic valve/
solenoid valve
YukenJapanHigh sensitive response
hydraulic valveHSUTIENTaiwanLonger span life
Material CylinderTan StarTaiwanAntia brasive
corrosion resistance
Longer span life
Electronic partsSchneider
Fuji
Fotek
France/Japan/TaiwanStable
High sensitive
hydraulic MotorWhiteUSALow noise
Servo PumpEckerleGermanyLow noise
Electrical RulerGefranItalyHigh Precise Control
TiebarGenaralTaiwanHigh hardness
SealHALLITEUKLonger span life
Proportional rejection valveYukenJapanHigh Precise Control
Longer span life
Oil CylinderLianhueiTaiwanAntia brasive
